Aura Series
DG850LP-MB
Low-Profile IoT
LoRaWAN850 MHzUltra Low-Profile
Industrial IoT · LoRaWAN · SCADA
— Application
The DG850LP-MB is precision-tuned for LoRaWAN Class A/B/C network deployments and industrial SCADA uplinks. Its ultra-low-profile form factor installs into constrained enclosures and DIN rail equipment where a standard stub antenna would compromise the IP rating of the host device.
— Technical Specifications
RF Performance
| Frequency Range | 850 / 915 MHz (LoRa ISM) |
| Gain | 2.15 dBi |
| VSWR | ≤ 1.5:1 |
| Impedance | 50Ω |
| Protocol Support | LoRaWAN Class A / B / C |
| Interference Rejection | MIOTY-rated |
Mechanical
| Connector | SMA |
| Profile | Ultra Low-Profile |
| Operating Temperature | -40°C to +70°C |
| Mounting | Panel / enclosure through-hole |
— Deployment Contexts
01
LoRaWAN Gateways
Class A/B/C compatible with MIOTY interference rejection for dense industrial sensor field deployments
02
SCADA & Telemetry
panel-mount installations inside IEC60068-rated enclosures with a flush-profile antenna requirement
03
Smart Infrastructure
water, gas, and electrical metering nodes where enclosure-flush antenna mounting is mandatory
